1/10 R/C Manta Ray (2018). Kommer som byggesett.
540 motor medfølger. Må kompletteres med:
Anbefales:
Tamiya har et bredt sortiment med maling. Du kan se hele sortimentet her.
Anbefalte farger:
PS-5 Black
PS-12 Silver
Fra produsenten:
Length: 395mm. Image shows painted and assembled kit.
Hip Hip, Hoo-Ray!
This re-release of the Manta Ray is certainly news to celebrate for fans of Tamiya vintage 4WD buggy models! The body – inspired by the watergoing ray of the natural world – is still a classic nearly 30 years on from its original release in 1990; it and the large rear wing are molded in lightweight and tough polycarbonate. Stylish dish type wheels are paired with spike tires for superlative grip on- or off-road. For those looking for even greater performance, why not pair with our dedicated Hop-Up Option parts set (47373)? |
A Rugged 4WD Chassis
This kit’s 4WD chassis is based around a bathtub frame with honeycomb rib pattern for excellent rigidity, and which also facilitates a low center of gravity thanks to a low attachment position for the battery pack. Its 4-wheel independent double wishbone suspension employs CVA oil dampers, while lightweight and durable hollow lower arms feature a smooth design to discourage dirt from sticking to them. Differential gears are contained in sealed gearboxes, each with a quick-access maintenance hatch. The 3-piece steering tie-rod gives sharp response, and ball adjusters allow easy altering of toe angle. |
Specifications
★Length: 395mm, Width: 250mm, Height: 145mm ★Wheelbase: 270mm ★Weight (excluding R/C equipment and battery pack): 1,100g ★Tread: 207mm (Front & Rear) ★Bathtub-type Chassis Frame ★Shaft-Driven 4WD ★Front/Rear 3-Bevel Differentials ★3-Piece Steering Tie-Rod ★4-Wheel Double Wishbone Suspension ★Tire Width/Diameter: 40/84mm (Front & Rear) ★CVA Short Oil Shock Units ★Gear Ratio=8.59:1 (with kit-included 21T pinion gear) ★Type 540 Motor ★Requires an Electronic Speed Controller (sold separately) |
Separately Required Items
★2-Channel R/C Unit with ESC ★Battery Pack & Charger ★R6/AA/UM3 batteries for transmitter |
